◆Place of Origin
China
◆Brand Name
HYH
◆Model Number
104-1007-006 M02187AC01AA0100010000000AAAAF
◆Minimum Order Quantity
1Set
◆Packaging Details
Paper and wooden packing
◆Delivery Time
1-4Working Days
◆Payment Terms
T/T, Western Union, L/C
Product Overview
We specialize in high-quality replacement hydraulic components, with a focus on reliable performance, fast delivery, and dedicated customer support. All our motors are backed by full quality inspections and a standard warranty, so you can trust them to keep your equipment running smoothly. Contact us today for bulk pricing, custom quotes, or technical support!
Key Features
✅ Direct OEM Fit: Precision-machined to match the original mounting dimensions, ports, and shaft specifications, ensuring hassle-free installation with no modifications required.
✅ Reliable Performance: Built with high-strength materials and advanced sealing technology to resist wear, corrosion, and fluid leakage, even under continuous heavy loads.
✅ Cost-Effective Replacement: A budget-friendly alternative to expensive OEM parts, without compromising on quality or performance.
✅ Wide Compatibility: Works seamlessly with standard hydraulic fluids and systems, suitable for both open and closed loop applications.
✅ Quality Assured: Every motor undergoes rigorous testing (pressure, flow, torque, and leak tests) to meet or exceed OEM performance standards.
Agricultural equipment (harvesters, sprayers, augers)
Material handling systems (forklifts, conveyor drives)
Forestry machinery (chippers, saw heads)
Industrial processing equipment and machine tools
Other model specifications
| 104-1001-006 | 104-1002-006 | 104-1003-006 | 104-1004-006 | 104-1005-006 |
| 104-1006-006 | 104-1007-006 | 104-1008-006 | 104-1009-006 | 104-1010-006 |
| 104-1011-006 | 104-1012-006 | 104-1013-006 | 104-1014-006 | 104-1015-006 |
| 104-1016-006 | 104-1017-006 | 104-1018-006 | 104-1019-006 | 104-1020-006 |
| 104-1021-006 | 104-1022-006 | 104-1023-006 | 104-1024-006 | 104-1025-006 |
| 104-1026-006 | 104-1027-006 | 104-1028-006 | 104-1029-006 | 104-1030-006 |
| 104-1031-006 | 104-1032-006 | 104-1033-006 | 104-1034-006 | 104-1035-006 |
| 104-1201-006 | 104-1202-006 | 104-1203-006 | 104-1204-006 | 104-1205-006 |
| 104-1206-006 | 104-1207-006 | 104-1208-006 | 104-1209-006 | 104-1210-006 |
| 104-1211-006 | 104-1212-006 | 104-1213-006 | 104-1214-006 | 104-1215-006 |
| 104-1216-006 | 104-1301-006 | 104-1302-006 | 104-1303-006 | 104-1304-006 |
| 104-1305-006 | 104-1306-006 | 104-1307-006 | 104-1308-006 | 104-1309-006 |
| 104-1310-006 | 104-1386-006 | 104-1860-006 | 104-3001-006 | 104-3002-006 |
| 104-3003-006 | 104-3004-006 | 104-3005-006 | 104-3006-006 | 104-3007-006 |
| 104-3008-006 | 104-3009-006 | 104-3010-006 | 104-3095-006 | 104-3100-006 |
| 104-3101-006 | 104-3102-006 | 104-3103-006 | 104-3104-006 | 104-3105-006 |
| 104-3106-006 | 104-3107-006 | 104-3108-006 | 104-3109-006 | 104-3110-006 |
| 104-3111-006 | 104-3112-006 | 104-3113-006 | 104-3114-006 | 104-3115-006 |
| 104-3116-006 | 104-3117-006 | 104-3118-006 | 104-3119-006 | 104-3120-006 |
| 104-3121-006 | 104-3122-006 | 104-3123-006 | 104-3124-006 | 104-3125-006 |
| 104-3126-006 | 104-3127-006 | 104-3128-006 | 104-3129-006 | 104-3130-006 |
| 104-3131-006 | 104-3132-006 | 104-3133-006 | 104-3134-006 | 104-3135-006 |
| 109-1001-006 | 109-1002-006 | 109-1003-006 | 109-1004-006 | 109-1005-006 |
| 109-1006-006 | 109-1007-006 | 109-1008-006 | 109-1009-006 | 109-1010-006 |
| 109-1101-006 | 109-1102-006 | 109-1103-006 | 109-1104-006 | 109-1105-006 |
| 109-1106-006 | 109-1107-006 | 109-1108-006 | 109-1109-006 | 109-1110-006 |
| 109-1116-006 | 109-1117-006 | 109-1173-006 | 109-1182-006 | 109-1201-006 |
| 109-1202-006 | 109-1203-006 | 109-1204-006 | 109-1205-006 | 109-1206-006 |
| 109-1207-006 | 109-1208-006 | 109-1209-006 | 109-1210-006 | 109-1211-006 |
| 109-1212-006 | 109-1213-006 | 109-1214-006 | 109-1215-006 | 109-1216-006 |
| 109-1217-006 | 109-1218-006 | 109-1219-006 | 109-1220-006 | 109-1221-006 |
| 109-1222-006 | 109-1223-006 | 109-1224-006 | 109-1225-006 |
| 114-1001-006 | 114-1002-006 | 114-1003-006 | 114-1004-006 | 114-1005-006 |
| 114-1006-006 | 114-1007-006 | 114-1008-006 | 114-1009-006 | 114-1010-006 |
| 114-1032-006 | 114-1033-006 | 114-1034-006 | 114-1035-006 | 114-1036-006 |
| 114-1037-006 | 114-1038-006 | 114-1039-006 | 114-1040-006 | 114-1041-006 |
| 114-1042-006 | 114-1043-006 | 114-1044-006 | 114-1045-006 | 114-1046-006 |
| 114-1047-006 | 114-1048-006 | 114-1049-006 | 114-1050-006 | 114-1051-006 |
| 114-1052-006 | 114-1053-006 | 114-1054-006 | 114-1055-006 |
| 129-0001-002 | 129-0002-002 | 129-0003-002 | 129-0004-002 | 129-0005-002 |
| 129-0006-002 | 129-0007-002 | 129-0008-002 | 129-0009-002 | 129-0010-002 |
| 129-0320-002 | 129-0522-002 | 129-0612-002 | 129-0712-002 | 129-0812-002 |
| 129-0912-002 | 129-1012-002 | 129-1112-002 | 129-1212-002 | 129-1312-002 |
| 129-1412-002 | 129-1512-002 | 129-1612-002 | 129-1712-002 | 129-1812-002 |
| 129-1912-002 | 129-2012-002 |
| 112-1001-006 | 112-1002-006 | 112-1003-006 | 112-1004-006 | 112-1005-006 |
| 112-1006-006 | 112-1007-006 | 112-1008-006 | 112-1009-006 | 112-1010-006 |
| 112-1098-006 | 112-1254-006 | 112-1331-006 | 112-1344-006 | 112-1362-006 |
| 112-1371-006 | 112-1380-006 | 112-1389-006 | 112-1398-006 | 112-1407-006 |
| 112-1416-006 | 112-1425-006 | 112-1434-006 | 112-1443-006 | 112-1452-006 |
| 101-1001-009 | 101-1002-009 | 101-1003-009 | 101-1004-009 | 101-1005-009 |
| 101-1006-009 | 101-1007-009 | 101-1008-009 | 101-1009-009 | 101-1010-009 |
| 101-1013-009 | 101-1023-009 | 101-1033-009 | 101-1043-009 | 101-1053-009 |
| 101-1063-009 | 101-1073-009 | 101-1083-009 | 101-1093-009 | 101-1103-009 |
| 103-1001-012 | 103-1002-012 | 103-1003-012 | 103-1004-012 | 103-1005-012 |
| 103-1006-012 | 103-1007-012 | 103-1008-012 | 103-1009-012 | 103-1010-012 |
| 103-1011-012 | 103-1012-012 | 103-1013-012 | 103-1014-012 | 103-1015-012 |
| 130-1001-003 | 130-1002-003 | 130-1003-003 | 130-1004-003 | 130-1005-003 |
| 130-1006-003 | 130-1007-003 | 130-1008-003 | 130-1009-003 | 130-1010-003 |
| 130-1024-003 | 130-1025-003 | 130-1026-003 | 130-1027-003 | 130-1028-003 |
| 130-1029-003 | 130-1030-003 | 130-1031-003 | 130-1032-003 | 130-1033-003 |
| Item | Specification |
|---|---|
| Compatible Models | Eaton Char-Lynn 104-1007-006, Danfoss M02187AC01AA0100010000000AAAAF |
| Type | Orbital Geroler Hydraulic Motor |
| Displacement | 19.2 cu.in/rev (315 ml/rev) |
| Max Continuous Pressure | 1766 PSI (12.2 MPa) |
| Max Intermittent Pressure | 2175 PSI (15 MPa) |
| Rated Torque | 450 N·m at 10 MPa |
| Shaft Type | 1" Straight Shaft with Keyway |
| Mounting Flange | 2-Bolt SAE Standard |
| Rotation | Bi-directional |
| Operating Temperature | -20°C to +80°C |
| Weight | 12 kg (approx.) |
Specifications:
| Series | 2000 - Standard |
| Displacement | 18.71 in³/r |
| Motor Port Size | 7/8-14 UNF-2B |
| Motor Port Type | SAE O-Ring |
| Shaft Type | Straight |
| Max Operating Temperature | 180 °F |
| Output Shaft Size | 1 in Straight - Woodruff Key |
| Overall Height | 6.96 in |
| Overall Length | 10.85 in |
| Overall Width | 5.16 in |
| Seal Type | Standard |
| Drain Connection Size | .4375-20 Unf-2b O-ring Port Size -4 |
| Operation Rating Description | Continuous Rating - Motor May Be Run Continuously At These Ratings. / Intermittent Operation - 10 Percent Of Every Minute / Peak Operation - 1 Percent Of Every Minute |
| Port Orientation | Staggered Ports |
| Replacement Balance Ring | 006 Design - 8915-000 - 1 Required |
| Replacement Buna Seal Kit | 006 Design - 61258-000 - 1 Required |
| Replacement Drive - Sold Separately | 006 Design - 21371-007 - 1 Required |
| Replacement Drive Valve | 006 Design - 8433-000 - 1 Required |
| Replacement Geroler - Sold Separately | 006 Design - 21625-007 - 1 Required |
| Replacement Housing Bearing Side Fnt | 006 Design - 21578-004 - 1 Required |
| Replacement Long Cap Screw Cap End | 006 Design - 14384-012 - 4 Required |
| Rplc Output Shaft And Bearing Kit | 006 Design - 21618-001 - 1 Required |
| Replacement Pin For Balance Ring | 006 Design - 14351-000 - 2 Required |
| Replacement Plate Valve | 006 Design - 22134-000 - 1 Required |
| Replacement Rear Housing | 006 Design - 21564-001 - 1 Required |
| Replacement Valve Sold Separately | 006 Design - 21466-000 - 1 Required |
| Replacement Viton Seal Kit | 006 Design - 61263-000 - 1 Required |
| Replacement Wear Place | 006 Design - 22102-000 - 1 Required |
| Replacement Pin For Balancing Ring | 006 Design - 14351-000 - 2 Required |
| Actual Mounting Flange | 2-Bolt Flange - Sae A - With 3-1/4 In. Pilot Dia. |
| Actual Output Shaft | Straight |
| Actual Port Type | .875-14 UNF-2B SAE O-Ring Ports - Staggered Ports |
| Continuous Flow Rate | 75 L/min |
| Intermittent Pressure | 240 bar |
| Max Continuous Oil Viscosity | 70 Saybold universal second |
| Maximum RPM-Continuous | 742 rpm |
| Port Configuration | .875-14 UNF-2B SAE O-Ring Ports - Staggered Ports |
| Mounting Type | 2-Bolt Flange - 3.25 in Pilot - SAE A |
